Filsorb ION

FILOSORB-ION

MIXED ADSORPTION MICRO-GRANULATED MEDIA | MOLECULAR & GAS-PHASE MEDIA

    • PRODUCT SPECIFICATIONS
    Product Category Fine Granular Activated Carbon
    Raw Material Coconut Shell Carbon, Ion-Exchange Resin & Synthetic Substrate Layer
    Media Constituents Plain Activated Carbon and Ion-Exchange Resin.
    The media can also be a blend of Plain Activated Carbon, Impregnated Activated Carbon and Ion-Exchange Resin.
    All chemical granules are bonded to the synthetic substrate layer.
    Media Efficiency (Substrate) EN 779         – M5 / M6 / F7 / F8 / F9
    ASHRAE 52.2 – MERV 10 / 12 / 13 / 14 / 15
    ISO 16890    – ePM10 60% / ePM10 70% / ePM1 60% / ePM1 70% / ePM1 80%
    Model FILOSORB-SERV FILOSORB-HIM FILOSORB-NAAC
    Base Weight 200g – 1600g 200g – 1600g 200g – 1600g
    Target Gas

    (Acid ~ Base ~ VOC ~ MIX)     		ACID BASE VOC
    (H2S, SO2, HCl, Cl, F...) (NH3, Amines, ...)
    Media (Activated Carbon, IER) Coconut Carbon Ion Exchange Resin Coconut Carbon
    Coconut Carbon
    Mesh 30*60 30*60 30*60
    CTC Value >90 >90 >85
    Treatment Agent KOH, K2CO3 Depends on Customer N/A
    KI, KMnO4
    Ratio% 8-12 Depends on Customer N/A
    Recyclable Yes
    Applications

      Medium to Heavy duty Molecular & odor control applications

    • High-End HVAC Systems
    • Cleanroom Inlet Filtration
    • Microelectronics Industry
    • Airports
    • Museums
    • Upscale Restaurants and Hotels
    • Industrial Buildings
    • Laboratories
    • Human Odors
    • Poultry Farms
    • Tobacco Smoke
    • Tar Odors
    • Toilet Odors
    • Paint Booths
    • Chemical Factories
